Start with an empty presentation. Insert a SmartArt diagram of type "Radial Cluster". Enter some dummy content, e.g. the words Center, Top, Right, Left. Save the file.
Unpack the file and examine layout1.xml. You will find attributes axis="ch ch" or ptType="node node node" or cnt="1 3 0". Such values are not allowed in the standard. And it is not clear how they are interpreted. If you use an extension to the standard, please document it. If an extension to the standard is not intended, please fix the "Radial Cluster" template.
Technical documents for protocols, computer languages, standards support, and data portability. The goal with Open Specifications is to help developers open new opportunities to interoperate with Windows, SQL, Office, and SharePoint.
Hello Regina,
Thank you for your question about Microsoft Open Specifications. One of the team members will review your question and contact you soon.
Regards,
Sreekanth Nadendla
Microsoft Open Specifications
Based on my research, the attributes ptType, cnt, and axis can each represent either a single value or a list of values.
With this in mind, it helps explain why scenarios such as axis="ch" can appear as a single value, or axis="ch ch" may represent a list of values within the same attribute.
To better interpret these values, I found the following documentation that may provide additional reference and context:
This information is provided as a convenience to you. These sites are not controlled by Microsoft, and Microsoft cannot make any representations regarding the quality, safety, or suitability of any software or information found there. Please ensure that you fully understand the risks before using any suggestions from the above link.
However, there should ideally be the latest official documentation that clearly explains this.
That said, I highly recommend sharing your feedback through Ideas · Community.
This is the official channel for submitting suggestions, and it ensures that your feedback reaches Microsoft’s development team, where it can help shape future updates and improve the overall experience.
I hope this brings some additional insight.
Note: Please follow the steps in our documentation to enable e-mail notifications if you want to receive the related email notification for this thread.
@Anonymous That said, I highly recommend sharing your feedback through Ideas · Community.
I have written https://feedbackportal.microsoft.com/feedback/idea/5cadb1b6-2d61-f111-89e7-7c1e52b8a25f
Hi Regina Henschel
Thank you for submitting the idea and sharing the link.
I’ve added my upvote and appreciate your contribution.
Hi @Regina Henschel , Thanks for submitting your feedback, I've added my upvote too. As always, thank you very much for your help with our documentation!
